Kona El Kahuna - 2023

Kona El Kahuna
$3,099.00
Color:
Gloss Plum w/ Metallic Brass & Matte Ink Decals
Please select options
Order now and pick up in-store for free

Details

The Kahuna is one of our best-selling hardtails. People love its simplicity and practicality. We brought that ethos to the El Kahuna and built a bike that was multipurpose—capable of riding the local singletrack for hours on end, and still have enough battery to go get the groceries on the way home. Its Shimano pedal-assist motor is powered by a semi-integrated battery and its 100mm fork provides just the right amount of suspension to absorb smaller hits on the trail. 29" wheels with 2.25" tires make this bike comfortable across all kinds of terrain. The El Kahuna the perfect all-rounder.

KONA 6061 ALUMINUM
Kona 7005 and 6061 Aluminum alloys are used extensively throughout our fleet of mountain and asphalt bicycles. A tough, durable, light alloy, both Kona 7005 and 6061 deliver fantastic, reliable performance that lasts for thousands of rides. Much of our 7005/6061 tubing is butted and/or formed, meaning the tubing's wall thickness can be increased or decreased, as well as shaped, so we can fine-tune a particular frame's strength and ride characteristics depending on its intended application.

INTERNAL HEADSET
Bearing cups are actually pressed into the frame and are easily removable. An internal headset also reduces stack height, so the height of the stem and bars are more adjustable, giving the rider the best fit possible.

TAPERED HEAD TUBE
More girth at the bottom of the head tube better distributes shock force, prolonging the bearing life of the headset itself and eliminating brake shudder, while providing confident steering performance. The inherent strength of its triangular design also means a stronger steering position and improved balance, giving the rider more control in rough terrain. A zero-stack, tapered head tube also puts strength where the load is going—into the lower headset cup—maximizing bearing durability where it's needed.

TUBELESS COMPATIBLE RIMS
Tubeless rims allow for tires with more puncture resistance; the ability to run lower tire pressure, which provides better tire grip on the trail; lower rolling resistance; and weight savings over traditional tube and tire systems.

Geometry Chart:
Frame SizeSmallMediumLargeX-Large
Seat Tube Length (mm) 370 420 470 530
Top Tube Length (mm) 581 607 633 665
Reach (mm) 404 428 453 484
Stack (mm) 619 623 628 633
Standover (mm) 738 742 747 766
Head Tube Angle 69° 69° 69° 69°
Head Tube Length (mm) 110 115 120 125
Seat Tube Angle 74° 74° 74° 74°
Chainstay Length (mm) 465 465 465 465
Bottom Bracket Drop (mm) 60 60 60 60
Bottom Bracket Height (mm) 315 315 315 315
Wheelbase (mm) 1134 1160 1187 1220
Front Center (mm) 676 701 728 761
Fork Length (mm) 506 506 506 506
Fork Offset (mm) 51 51 51 51
Sizes:
Frame SizeHeight (inches)Height (cm)Inseam (inches)Inseam (cm)
X-Small 4'10"-5'1" 147-155cm 24"-27" 61-69cm
Small 5'0"-5'3" 152-160cm 26"-29" 66-74cm
Small, Medium 5'2"-5'7" 157-170cm 27"-30" 69-76cm
Medium 5'6"-5'10" 168-178cm 29"-31" 74-79cm
Medium, Large 5'9"-6'0" 175-183cm 30"-33" 76-84cm
Large, X-Large 5'11"-6'2" 180-188cm 32"-35" 81-89cm
Large, X-Large 6'1"-6'5" 185-196cm 33"-36" 84-91cm

Specs

Frame Kona 6061 Aluminum Butted
Fork RockShox 35 R Coil or Suntour XCR34 Air 100mm Tapered 110 Spacing
Rims WTB ST i27 TCS 2.0
Hubs Front: Shimano 110x15mm
Rear: Shimano 135x10mm
Spokes Stainless 14g
Tires WTB Trail Boss 29x2.25"
Crankset FSA E-Bike
Chainrings 36t
Shifters Shimano Deore
Rear Derailleur Shimano Deore
Cassette/Freewheel Shimano Deore 11-46t 10spd
Chain Shimano HG54
Brakes Shimano MT410
Rotors Front: Shimano RT10 180mm (centerlock)
Rear: Shimano RT10 160mm (centerlock)
Brake Levers Shimano MT401
Handlebars Kona XC/BC Riser
Tape/Grips Kona Key Grip
Stem Kona XC
Headset FSA No.57BP
Seatpost Kona Thumb w/Offset 31.6mm
Saddle WTB Volt
Pedals Kona JS2
Motor Shimano E6100 20MPH
Battery Shimano 504Wh
Controller/Display Shimano SC-E7000 Display
Charger Shimano STEPS 2A

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
Gloss Plum w/ Metallic Brass & Matte Ink Decals / Small B36EKH01 210000087272
Gloss Plum w/ Metallic Brass & Matte Ink Decals / Medium B36EKH03 210000087273
Gloss Plum w/ Metallic Brass & Matte Ink Decals / Large B36EKH05 210000087274
Gloss Plum w/ Metallic Brass & Matte Ink Decals / X-Large B36EKH06 210000087275
