Cinelli Pressure Frame Kit - 2023
Details
Born to race, this monocoque high modulus carbon T800 fiber aero road bike is designed to cut through the air. Password: integrate! The new born Cinelli aerodynamic racing frame integrates anything possible: the special aero seat tube, the custom colour FSA Vision Metron 5D ACR fully integrated aero handlebar, with integrated headset, cockpit and fork, for the cleanest cable routing solution and fastest racing geometry ever. The bicycle natural choice is for electronic groupset.
Disc brake and thru axle with the dropped seat stays design increase the aerodynamics alongside with the global stiffness of the frame, for best reactivity and maximum control. Pressure.
Vision Metron 5D handlbar’s ACR system, with fully integrated bar, cockpit headset and fork, coupled with the use of PU Molds in the curing for the cleanest and most efficient internal wire passage, emphasize the purest aesthetic and Pressure artwork.
Aero seat tube and dropped seat stays are functional to best aerodynamics and stiffness and join forces with the other aero elements of the frame for best control and power.
The thru axle and disc brake choice with internal wire routing allows for the cleanest and fastest design, in an overall geometry which leads to the most compact and aerodynamic position of the rider.
Frame 990g (size M) - Fork 390g (uncut)
Specs
| Frame | Columbus Carbon Monocoque T800 |
|---|---|
| Fork | Columbus Disc 1-1/2” Carbon Monocoque Internal Cable Routing |
| Axles | Rear TA Ø 12x142mm - M12x165 / Front TA Ø 12x100mm - M12x120 |
| Tires | up to 700x30 mm |
| Bottom Bracket | Press Fit 86,5 x 41 mm |
| Front Derailleur | Braze-On |
| Brakes | Flat Mount Disc Brake, Rotor Size Up To 160 mm |
| Handlebars | XS 100x40 - S 100x40 - M 110x42 - L 110x42 - XL 120x42 Included |
| Headset | IS 52/28,6 | IS 52/40 FSA ACR 1-1/2” (included) |
| Seatpost | Aero (included) / Carbon Rail Comp. / L 300 (XS) - L 350 (S-M-L-XL) |
| Accessories & Extras | Extra hanger / Di2 / EPS Cable Inserts / F-R Skewers |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Triple Grey / X-Small | 8051597226146 | 142PIG460 | 210000087995 |
| Triple Grey / Small | 8051597226153 | 142PIG490 | 210000087996 |
| Triple Grey / Medium | 8051597226160 | 142PIG520 | 210000087997 |
| Triple Grey / Large | 8051597226177 | 142PIG550 | 210000087998 |
| Triple Grey / X-Large | 8051597226184 | 142PIG580 | 210000087999 |
| Rock The White / X-Small | 8053323627517 | 141PRS460 | 210000088000 |
| Rock The White / Small | 8053323627524 | 141PRS490 | 210000088001 |
| Rock The White / Medium | 8053323627531 | 141PRS520 | 210000088002 |
| Rock The White / Large | 8053323627548 | 141PRS550 | 210000088003 |
| Rock The White / X-Large | 8053323627555 | 141PRS580 | 210000088004 |
| Team Edition / X-Small | 8057714327345 | 142POL460 | 210000088005 |
| Team Edition / Small | 8057714327352 | 142POL490 | 210000088006 |
| Team Edition / Medium | 8057714327369 | 142POL520 | 210000088007 |
| Team Edition / Large | 8057714327376 | 142POL550 | 210000088010 |
| Team Edition / X-Large | 8057714327383 | 142POL580 | 210000088008 |
| Triple White / X-Small | 8051597229208 | 142PIW460 | 210000088009 |
| Triple White / Small | 8051597229215 | 142PIW490 | 210000088011 |
| Triple White / Medium | 8051597229222 | 142PIW520 | 210000088012 |
| Triple White / Large | 8051597229239 | 142PIW550 | 210000088013 |
| Triple White / X-Large | 8051597229246 | 142PIW580 | 210000088014 |
