Cinelli Nemo TIG Disc Frameset - Raw

Cinelli Nemo TIG Disc Frameset - Raw
$1,500.00
$2,750.00
Size: Select size
Please select options Unavailable

Details

These frames and forks are in their unfinished, primed state and are ready to be painted.

Included are frame, fork, Columbus Spirit decal, headset, water bottle screws, front and rear thru axles, cable guides, seat post binder bolt, front derailleur clamp, Columbus “Guide to Steel” book, and owners manual. Cinelli decals are NOT included.

The Nemo TIG is Cinelli’s latest Made in Italy high-performance steel road frame. It looks and rides the way in which the legendary Supercorsa – the world’s longest running production steel frame – might have looked had it been designed for racing today rather than in the 1950s.

The first prototypes of this frame were born according to the specifications of a recently retired Italian professional rider working at Cinelli who, seduced by the Columbus tubing being manufactured on the factory floor attached to the Cinelli offices, demanded that Cinelli produce a pure racing steel frame that took full advantage of the latest advances in high tech steel tubing manufacturing.

Accordingly the Nemo has been designed for riders used to riding high-end carbon fiber racing frames, unwilling to sacrifice “race feeling”, but looking for something incomparably pleasurable to ride in the way only a steel frame can be. It employs custom-shaped Columbus Spirit triple-butted tubes (the seat stays, for example, are the identical shape of those found on the original 1981 Cinelli Laser road model), with a highly contemporary 44mm mega-oversized downtube, conical CNC’d head tube and Columbus’ latest Futura straight blade monocoque carbon fiber fork.

Allow about 1 month for the frame to be painted.

The Nemo TIG is Cinelli’s latest Made in Italy high-performance steel road frame. It looks and rides the way in which the legendary Supercorsa – the world’s longest running production steel frame – might have looked had it been designed for racing today rather than in the 1950s.

The first prototypes of this frame were born according to the specifications of a recently retired Italian professional rider working at Cinelli who, seduced by the Columbus tubing being manufactured on the factory floor attached to the Cinelli offices, demanded that Cinelli produce a pure racing steel frame that took full advantage of the latest advances in high tech steel tubing manufacturing.

Accordingly the Nemo has been designed for riders used to riding high-end carbon fiber racing frames, unwilling to sacrifice “race feeling”, but looking for something incomparably pleasurable to ride in the way only a steel frame can be. It employs custom-shaped Columbus Spirit triple-butted tubes (the seat stays, for example, are the identical shape of those found on the original 1981 Cinelli Laser road model), with a highly contemporary 44mm mega-oversized downtube, conical CNC’d head tube and Columbus’ latest Futura straight blade monocoque carbon fiber fork.

New design for the 12mm through axle dropouts: the engraving of the famous ‘C’ wing enhances the frame and the through axle facilitates fitting disc brakes while maintaining the wheels alignment.

Specs

Frame COLUMBUS Spirit HSS Tubeset
Fork COLUMBUS FUTURA Disc 1-1/8” - 1-1/2”
Axles Rear TA Ø12x142mm / M12x1,5 L173mm skewer Front TA Ø12x100mm / M12x1,5 L119mm skewer
Tires up to 700x28c
Bottom Bracket up to 700x28c
Front Derailleur Clamp Ø31,7mm
Brakes Flat mount disc brake Rotor size up to 160mm
Headset IS 42/28,6 | IS 52/40
Seatpost Ø 27,2mm
Accessories & Extras Front derailleur clamp / Front&Rear Skewer / Headset

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
X-Small BI3517 210000094188
Small BI3518 210000094189
Medium BI3519 210000094190
Large BI3520 210000094191
